Brief introduction:
FO-718PL25 pleated media filter micron pre-filter and coalescer is used to remove solid particulate contaminants from aviation jet fuel, diesel fuel, industrial fluids and insulating oils used in power facilities. The function of FO-718PL25 is to improve the cleanliness of oil, protect the long-term, efficient and safe operation of industrial equipment, and effectively ensure the quality requirements of oil. Manufacturing materials range from cellulose paper to high-efficiency synthetic materials in various micron grades.
FO718 PL25 Specifications:
• Collapse:75 psi
• Operating pH range:5 - 9
• Micron ratings: from 1/4 to 75
• Nominal filtration efficiency:98%+
• Maximum operating temperature:250°F (121.1°C)
• Recommended changeout differential pressure:25 psid
FO718 PL25 Features:
Large surface area:Allows high flow rates,low initial pressure drop,maximum contaminant capacity.
Resin impregnating medium:Maintains strength,resists the effects of water and heat.
High collapse strength:Heavy carbon steel end caps and center tubes provide a safe margin against pressure fluctuations with 75 psi.
Coated steel parts:Resistant to corrosion by most industrial fluids.
Corrugated filter material:Prevents folds from snapping and ensures that all filters are used.
Buna-N Gaskets:The best universal gasket material to ensure reliable sealing in most fluids.
Thermosetting adhesive material:Durable end caps and media bonding can prevent internal bypass.
Threaded base element:can be used for easier installation.
